1.5m³ Self Loading Concrete Mixer Truck
EP's 1.5 self loading concrete mixer truck is an on-site construction vehicle that combine features with concrete batch processing equipment, concrete transport and concrete mixing station. Self loading concrete mixer truck combines the features of self-loading, weighing, mixing and discharging. It can maximize and improve the job efficiency and reduce the production cost and time. This kind of equipment is especially suitable for the infrastructure construction of small and medium-sized projects.
Production Types
Mixer Types
Name:
1.5m³ Self Loading Concrete Mixer Truck
Chassis type:
Articulated Chassis
Net weight:
5500kg
Output capacity:
1.5/1.6/2.2/3.5/4.0/5.0m3 per batch
Share With:
Features
Technical Info
Inquiry
1.5m³ Self Loading Concrete Mixer Truck
  • The self loading concrete mixer truck is equipped with a powerful engine and four-wheel steering, just like a small car, and the operator can drive it to where it needs to go. It is very convenient to load cement, aggregate, stone and other materials. The self-discharging cement truck has a powerful automatic feeding system, which can easily load cement, sand, stone, water and other raw materials into the mixing tank, and maintain the uniformity and quality stability of the concrete during transportation.
  • The articulated body design gives the vehicle greater flexibility and is particularly suitable for narrow worksites and complex road conditions. The presence of hinge points allows the front and rear parts of the body to move independently, thus increasing the flexibility of cornering and handling. Suitable for urban center area, highways, large projects and construction sites and other narrow sites.
  • The mixing drum is equipped with spiral blades, which can be continuously mixed during the driving process to ensure uniform and high quality concrete. Users can adjust the mixing time and speed through the control system to meet different construction needs. After mixing is complete, the mixing drum can be turned over by the hydraulic system to unload the concrete directly into the construction point or the formwork, simplifying the operation process.
  • Articulated self-feeding mixer trucks usually use four-wheel drive and powerful engines, with strong off-road capabilities, suitable for a variety of complex road conditions. At the same time, the integrated design enables it to quickly move to different construction points, greatly improving construction efficiency.
Parameters Of 1.5m³ Self-Loading Mixer Truck
Name 1.5m³ Self Loading Concrete Mixer Truck
Overall Size 6180*2270*2626mm(3434mm)
Chassis Off-Road
Tread 1600mm
Wheelbase 2500mm
Loader Bucket Capacity 0.4cbm
Loader Bucket Control Hydraulic
Tilt Angle 30%
High Speed 0-25km/h
Tyre Model 20.5/70-16 steel tyre
Engine Brand YUNNEI
Mixing Drum Full Capacity 2.2cbm
Mixing Drum Work Capacity 1.6cbm
Mixing Drum Bank Angle 16°
Chute Swing Angle ≥60%
Chute Angle Control Hydraulic
Chute Size 100cm
